    250V Thermal Fuse 150C 20A 25A 30A 40A 50A 60A Plastic Case for Long-Term

    Ask Lasest Price
    Brand Name : Lin Kun
    Model Number : 5mm-45mm
    Certification : RoHS
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 100,000 pieces/month
    Delivery Time : 5-7 days
    • Product Details
    • Company Profile

    250V Thermal Fuse 150C 20A 25A 30A 40A 50A 60A Plastic Case for Long-Term

    Product Description:

    Y Series 250V Square Type Electric Motor Radial Temperature Fuse Link Cutoff Thermal Fuses


    Rated current: 1A to 20A

    Rated voltage: 250V

    Action temperature: 75℃ to 150℃

    Case: Plastic

    Shape: Square


    Model NoFunciton Tcmpcarturc (℃)Fusing Temeperature (℃)Holding Temperature (℃)Maximum Temperature Limit(℃)Voltagc Rating (V)Amper Rating (A)
    Y0175℃72±1551302501——20
    Y0276℃73±1551302501——20
    Y0380℃75±2581302501——20
    Y0585℃80±2621302501——20
    Y0690℃85±2651302501——20
    Y0795℃90±1681302501——20
    Y0898℃96±1701302501——20
    Y09100℃97±1721502501——20
    Y10102℃98±1721502501——20
    Y11103℃99±2731502501——20
    Y12105℃100±2751502501——20
    Y18110℃105±1801502501——15
    Y20115℃111±2871502501——15
    Y28120℃115±1901502501——20
    Y30125℃121±2951502501——20
    Y32126℃121±2951502501——20
    Y33127℃122±2961502501——20
    Y35130℃126±11021502501——20
    Y36133℃130±11031502501——20
    Y38135℃130±11051502501——20
    Y39136℃131±11051502501——20
    Y46140℃136±11101602501——20
    Y48145℃140±11141802501——20
    Y50150℃146±11201802501——20

    Structure
    The thermal fuse is composed of plastic shell, low melting point alloy wire, special resin, lead copper wire and sealing resin.


    Apprearance
    The marking must be clear; the sealing resin should fill the mouth and it is acceptable; the lead tin-plated layer is good; there is no oxidized black spot damage; the shell has no damage marks, perforations, etc.


    Y Series 250V Thermal Cutoff Fuses 0

    ABCDE
    5.1±0.25.4±0.22.4±0.20.5±0.0270±2

    Testing Standard

    ItemsThermal fuseModel No.RH(Y)StandardUL1020
    Test itemsUnitSafety standardTesting equipment
    Action temperature detection+0
    TF
    -10
    thermotank
    High pressure testV1000+2 times the rated voltageWithstand voltage tester
    Insulation resistance detectionMΩ>2Digital Megger
    Internal resistance detectionΩ<0.028Bridge resistance tester
    High pressure test after temperature checkV>500Withstand voltage tester
    Insulation resistance test after temperature testMΩ>0.2Digital Megger
    Distortion detectionEach lead is bent 90° at a distance of 10mm from the thermal fuse, and then twisted in the opposite direction by 180° without damaging the components.Manual operation
