    MZ10 Series MZ10B10D120C100R300V PTC Positive Temperature Coefficient Thermistor Overcurrent Protection Dedicated To Sew

    Ask Lasest Price
    Brand Name : linkun
    Model Number : PTC thermistor for protectionMZ10B10D120C100R300V
    Certification : CE / ROHS / UL / TUV / SGS
    Price : Negotiation
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 24 million per year
    Delivery Time : Negotiation
    • Product Details
    • Company Profile

    MZ10 Series MZ10B10D120C100R300V PTC Positive Temperature Coefficient Thermistor Overcurrent Protection Dedicated To Sew

    Small Volume Large Power PTC Thermistor For Protection For High Pulse Currents And A High Number Of Inrush-Power Cycles

    The thermistor has high sensitivity, wide operating temperature range, small size, easy to use, easy to process into complex shapes, good stability, and strong overload capacity. In the application, it can not only measure temperature as a measuring element, but also control temperature and circuit compensation element as a control element. According to different temperature coefficients, thermistors are divided into positive temperature coefficient (PTC) thermistors and negative temperature coefficient (NTC). PTC thermistor is a thermistor with positive temperature coefficient, which belongs to semiconductor linear element and is sensitive to temperature. The resistance value is proportional to the temperature change. Within a certain temperature range, the resistance changes with temperature, and the resistivity also increases with temperature. PTC thermistor has three characteristics: voltage-current, current-time, resistance-temperature. The voltage-current characteristic is a volt-ampere characteristic, which refers to the relationship between the voltage clamped at the terminal of the thermistor and the current that reaches the steady state of thermal equilibrium.

    Product Description​

    ◆ Self protecting in case of overload with no risk of over-heating
    ◆ Encased thermistor disk with clamp contacts for high reliability
    ◆ For high pulse currents and a high number of inrush-power cycles
    ◆ Can handle 2kv energy-limited peak voltage

    Application

    ◆ Automotive on-board charging
    ◆ Discharge - charge circuits
    ◆ Power inverters
    ◆ Server power surge protection
    ◆ Servo motor control
    ◆ Welding equipment
    Structures and Dimensions​

    Electrical Specifications

    Order NumberMax. Voltage
    Vmax(VAC)
    Max. Link Voltage
    VLmax(VDC)
    Resistance At 25°C
    R25(Ω)
    Curie Temp.
    TC (°C)
    Heat Capacity
    Cth(J/K)
    Thermal Cooling Time Constant
    τth (s)
    Dimensions(mm)
    DHT
    MZ21X209-700□B6#260370701200.4709.013.57.5
    MZ21X209-121□B6#2603701201200.6809.013.57.5
    MZ21X209-151□B6#2603701501200.6809.013.57.5
    MZ21X212-250□B8#28040025120110012.516.55
    MZ21X213-500□B8#280400501201.412013.018.07.5
    MZ21X213-800□B8#280400801201.412013.018.07.5
    MZ21X413-600□C5#350500601401.4510513.5177
    MZ21X315-560□D4#440620561302.110015.019.07.5
    MZ21X213-121□D4#4406201201201.412013.018.07.5
    MZ21X417-600□D4#440625601402.312017217.5
    MZ21X413-121□D4#4406251201401.4510513.5177
    MZ21X213-151□D4#4406201501201.412013.018.07.5
    MZ21X209-501□D4#4406205001200.6809.013.57.5
    MZ21X109-103□D4#44062011001150.6809.013.57.5
    MZ21X417-121□D6#4606501201402.312017217.5
    MZ21X315-120□D8#4806801201302.110015.019.07.5
    MZ21X413-251□D8#4806802501401.4510513.5177
    MZ21X113-501□E6#5608005001151.412013.018.07.5
    MZ21X413-501□E6#5608005001401.4510513.5177
    MZ21X417-251□F0#6008502501402.312017217.5
    MZ21X413-102□F0#60085010001401.4510513.5177
    MZ21X417-501□G0#70010005001402.312017217.5

    Common models of LKMZB series overcurrent protection PTC thermistor

    ModelCurieResistanceActionNo actionMaximumNaximumDimensions
    temperaturetypical valueelectric currentelectric currentelectric currentWork
     @25℃@60℃@25℃Voltage
    Tc(℃)Rn(Ω)It(mA)Ih(mA)Imax(A)Vmax(V)DmaxHmax
    LKMZB-03I202-302R85±725001630.24204.05
    LKMZB-03I102-202R85±715001840.24204.05
    LKMZB04I801-122R85±710002560.24204.55
    LKMZB-04I501-801R85±76502870.24204.55
    LKMZB-04I301-501R85±74003280.24204.55
    LKMZB-04M101-202R105±715002560.24204.55
    LKMZB-04M801-122R105±710002880.24204.55
    LKMZB-04M501-801R105±765030100.24204.55
    LKMZB-06S102-202R115±7150030100.34206.55
    LKMZB-06S801-122R115±7100035120.34206.55
    LKMZB-06S601-901R115±775042140.34206.55
    LKMZB-06S501-801R115±765045150.34206.55
    LKMZB-06S401-601R115±750050160.34206.55
    LKMZB-06S201-401R115±730060200.34206.55
    LKMZB-06S151-251R115±720075250.32656.55
    LKMZB-06S101-201R115±715080280.32656.55
    LKMZB-06S900-151R115±712090300.32656.55
    LKMZB-06M600-100R105±780100320.32656.55
    LKMZB-06M400-800R105±760120350.32656.55
    LKMZB-08S301-501R115±740080200.842085
    LKMZB-08S201-301R115±725080250.842085
    LKMZB-08S151-251R115±7200100280.842085
    LKMZB-08S900-151R115±7120120350.842085
    LKMZB-08S600-101R115±780140400.842085
    LKMZB-08S400-800R115±760160500.826585
    LKMZB-08S300-500R115±740180600.826585
    LKMZB-10S300-500R115±74020070326595
    LKMZB-10S200-300R115±72525080326595
    LKMZB-13S200-300R115±7253001004265135
    LKMZB-13S100-200R115±7153601204265135
    LKMZB-16S200-300R115±7253601208265165
    LKMZB-16S100-200R115±7154201408265165
    LKMZB-16S080-150R115±7124201608265165

    Note: Various types of products can be customized according to customer requirements, and the maximum non-operating current value can reach 400mA@60℃.

    Note:

    1.is the resistance tolerance M:±20% X:±25% N:±30% S: Special
    2. is the internal control code
    3.The F value can be selected for 5mm, 7.5mm, 10mm
    4.The L value canbe selected for 3mm, 20mm, 25mm, 35mm
    5.The d value can be selected for 0.6mm, 0.8mm, 1.0mm
    6.Other type are available on request
