    MF75 High Power NTC Thermistor High Current Imax (A) 90A 40mm/45mm/50mm Multiple Diameters

    Ask Lasest Price
    Brand Name : lin kun
    Model Number : ,MF75 NTC thermistor
    Certification : ROHS,UL
    Price : Negotiate
    Delivery Time : 10-20 workdays
    Payment Terms : T/T
    Supply Ability : 20,000,000PCS per week
    • Product Details
    • Company Profile

    MF75 High Power NTC Thermistor High Current Imax (A) 90A 40mm/45mm/50mm Multiple Diameters

    MF75 High Power NTC Thermistor High Current Imax (A) 90A 40mm/45mm/50mm Multiple Diameters1.High-power NTC thermistor MF75 series

    R25(Ω): 0.2~20 Imax(A):90A

    [Product features] High current, long life, high reliability

    [Product use] High-power switching power supply, conversion power supply, UPS power supply

    2.Features

    ● High power, strong surge current suppression capability.

    ● Large material constant (B value), small residual resistance, and low power consumption.

    ● High current, long life, and high reliability.

    ● Easy to install on circuit boards, full series, and wide application range.


    3.MF75 Dimensions (mm)

    Body sizeΦ40Φ45Φ50
    (Dmax)/Diameter989292
    (Tmax)/Thickness464646
    (F±1.5)/Pitch303030
    (L±2)/Lead length404040
    Lead Height(Ho max)110110110
    Lead width(W±0.2)12.012.012.0
    Lead thickness(H±0.1)1.21.21.2

    Body sizeΦ40Φ45Φ50
    (Dmax)/Diameter929292
    (Tmax)/Thickness464646
    (F±1.5)/Pitch303030
    (L±2)/Lead length404040
    Lead Height(Ho max)110110110
    Lead width(W±0.2)121212
    Lead thickness(H±0.1)1.21.21.2
    Width of lower lead (W1±0.2)888

    4. MF75 high-power NTC thermistor series

    ●Main Technical parameters

    4.1 Body diameter Φ40mm

    P/NR25±20%(Ω)Thermal sensitive index B±10%(K)Max steady state current Imax(A)Approx R of Max current Rmax(Ω)Max power dissipation Pmax(W)Dissipation factor(mW/C)Thermal time constant (s)Max impulse capacitance (uF)240VAC
    MF75-0.2/550.22600550.00730≥55≤3508000
    MF75-1/4512600450.016800
    MF75-2/3522600350.0146800
    MF75-5/2753000270.0284700
    MF75-8/2283200220.0343300
    MF75-10/21103200210.0383300

    4.2 Body diameter Φ45mm

    P/NR25±20%(Ω)Thermal sensitive index B±10%(K)Max steady state current Imax(A)Approx R of Max current Rmax(Ω)Max power dissipation Pmax(W)Dissipation factor(mW/C)Thermal time constant (s)Max impulse capacitance (uF)240VAC
    MF75-0.2/700.22600700.00645≥70≤48011500
    MF75-0.5/550.52600550.0078000
    MF75-1/5212600520.0098000
    MF75-2/4522600450.0128000
    MF75-5/3553000350.0256800
    MF75-10/28103200280.0324700

    4.3 Body diameter Φ50mm

    P/NR25±20%(Ω)Thermal sensitive index B±10%(K)Max steady state current Imax(A)Approx R of Max current Rmax(Ω)Max power dissipation Pmax(W)Dissipation factor(mW/C)Thermal time constant (s)Max impulse capacitance (uF)240VAC
    MF75-0.2/900.22600900.00455≥90≤65015000
    MF75-1/6012600600.00811500
    MF75-2/5022600500.01111500
    MF75-5/4053000400.0228000
    MF75-8/3283200320.0286800
    MF75-10/30103200300.036800

    5.Application Scope


    MRI equipment, high-power audio amplifiers, high-power toroidal transformers.

    Solar panel arrays with large-capacity power inverters.

    Industrial robots driven by high-voltage power supplies.

    Product Description:

    This product is designed with a thickness of 1.4 ~ 1.6 Mm, making it a perfect fit for a variety of electronic devices. The NTC Thermistor is a MF11 temperature compensated thermistor that is capable of providing precise temperature readings in a range of environments. Additionally, this product is designed with a MF55 film thermistor, which adds to its overall accuracy and reliability.

    With its analog output signal type, the NTC Thermistor is capable of providing accurate temperature readings in a variety of applications. This product is ideal for use in automotive, medical, and industrial applications where precise temperature control is essential.

    Overall, the NTC Thermistor is a high-quality temperature sensor that is designed to provide accurate temperature readings in a range of environments. With its precise temperature compensation and film thermistor design, this product is an ideal choice for anyone looking for a reliable and accurate temperature sensor.

    Features:

    • Product Name: NTC Thermistor
    • Beta Value: 3100~4500
    • Lead Style: Straight Lead; Bend Lead
    • Lead Wire Material: Copper Wire
    • Thickness: 1.4 ~ 1.6 Mm
    • Operating Temperature Range: -55°C To 125°C
    • Related Products:
      • MF11 temperature compensated thermistor
      • MF52 temperature measuring thermistor
      • MF5 Single-ended glass sealed thermistor

    Technical Parameters:

    Part NumberMF73T-1 2/25
    Thermal Shock Resistance300 Cycles
    Mounting TypeSurface Mount
    Beta Value3100~4500
    Maximum Power Rating100mW
    Lead Length30mm
    Output Signal TypeAnalog Type
    Thickness1.4 ~ 1.6 Mm
    Lead StyleStraight Lead; Bend Lead
    ResistanceR25℃=2kΩ

    The NTC Thermistor product is an analog type temperature measuring thermistor. It is not the same as the MF58 glass sealed thermistor or the MF55 film thermistor.

    Applications:

    Lin Kun NTC Thermistor is a temperature measuring device, manufactured in Dong Guan, China. It is a reliable product that comes with ROHS and UL certifications. The product model number is NTC Thermistor, and it is available at a minimum order quantity of 5000 PCS. The product is priced at 0.045 USD/PCS and comes in bulk packaging, with 500pcs per polybag. The delivery time for the product is 7 workdays, and payment terms are T/T. The product has a supply ability of 20,000,000PCS per week.

    The Lin Kun NTC Thermistor is a chip-based device that operates in the temperature range of -55°C to 125°C. The device has a thermal shock resistance of 300 cycles, which makes it suitable for use in harsh environments. The lead wire material used in the product is copper wire, and the lead length is 30mm.

    The Lin Kun NTC Thermistor is available in three types: MF5 Single-ended glass-sealed thermistor, MF52 temperature measuring thermistor, and MF55 film thermistor. The MF5 Single-ended glass-sealed thermistor is commonly used for temperature measurement in household appliances, such as air conditioners, refrigerators, and water heaters. The MF52 temperature measuring thermistor is used in temperature control devices, such as thermostats and temperature sensors. The MF55 film thermistor is used in medical equipment, automotive systems, and other industrial applications.

    The Lin Kun NTC Thermistor is a versatile product that can be used in various applications. The product is suitable for use in temperature control systems, temperature sensing devices, and temperature measurement instruments. The product is widely used in the electronics industry, medical equipment, automotive systems, and other industrial applications.

    Customization:

    The minimum order quantity for our NTC thermistors is 5000 PCS, and they are priced at 0.045 USD/PCS. Our packaging details include bulk packaging with 500pcs per polybag. Delivery time takes only 7 workdays, and we accept T/T as payment terms. Our supply ability is 20,000,000PCS per week.

    Our NTC thermistors have a resistance of R25℃=2kΩ and a thermal shock resistance of 300 cycles. The lead wire material is made from copper wire, and the part number is MF73T-1 2/25. The thickness of our NTC thermistors ranges from 1.4 to 1.6 mm.

    Customize your NTC thermistors to fit your specific needs. Contact Lin Kun today to learn more about our customization services.

    Support and Services:

    The NTC Thermistor product offers top-notch technical support and services to ensure optimal performance and customer satisfaction. Our team of experts is available to assist with any technical questions or issues that may arise, providing prompt and effective solutions. Our services include:

    • Customized product design and development
    • Product testing and evaluation
    • Technical consultation and support
    • Quality control and assurance
    • On-site installation and training
    • Maintenance and repair services

    With our comprehensive range of technical support and services, we are committed to meeting the needs of our customers and ensuring the highest level of product performance and reliability.

    Packing and Shipping:

    Product Packaging:

    The NTC Thermistor product is securely packaged in a small, sturdy cardboard box to prevent any damage during shipping. The product is placed in a clear plastic bag with a label indicating the product name and specifications. The cardboard box is then sealed with tape to ensure it stays closed during transit.

    Shipping:

    The NTC Thermistor product is shipped via standard ground shipping. The product is usually shipped within 1-2 business days of receiving the order. The estimated delivery time varies depending on the destination, but typically takes between 3-7 business days. Tracking information will be provided once the product has shipped.
